MCX4 Controller

$719.00

$799.00
SAVE $80.00 (10%)
SKU: ENV-AT-MCX4-1

GrowControlTM MCX4 climate controller combines Agrowktek's SXE environment sensor/controller with an RX4i intelligent four-outlet relay to form a powerful, autonomous environmental controller for a single basic zone.

More Info

-

Share:

Overview

GrowControlTM MCX4 climate controller combines Agrowktek’s SXE environment sensor/controller with an RX4i intelligent four-outlet relay to form a powerful, autonomous environmental controller for a single basic zone. Sense and control temperature, humidity and CO2 with day and night set points. Each of the 120V outlets can be programmed independently for a specific sensor-based control, 24-hour timer and cycle timer. A light sensor on the top of the SXE controller detects day or night from ambient light levels. Precision sensors and rugged relays offer reliable and accurate control of environments large and small in an economical, easy to use package. Built on a decade of proven technology and components with new, enhanced capabilities to meet the growing demand for highly reliable environmental control applications.

The controller’s built-in color display provides an interface for monitoring the sensor readings and configuring the control settings. Also includes features such as:

  • High/low history
  • Graphical history
  • Alarm set points with Buzzer
  • Sensor calibration

Sensors

icon Air Temperature: -20 – 60°C
icon Relative Humidity: 0-99% RH (80% operating)
icon Light (Irradiance): 0-1000 Watts/m2
icon Carbon Dioxide (optional): 0-10,000 ppm

Functions

Heating & Cooling
Humidification & Dehumidification
CO2 Inject & Exhaust/Alarm
24-Hour Timers & Repeat Cycle Timers
Day & Night Set-Points w/Light Sensor
Visual & Audible Alarms
High-Temperature Lights Shutdown

RX4i relay includes four independent, programmable 120V outlets.

Options

CO2 ppm Sensor
Upgrade the MCX4 system to include a CO2 ppm sensor module to monitor and control CO2.
WiFi Module
Upgrade the MCX4 controller to include a WiFi module for access to the system via a phone or web browser (coming soon.)
Power Cord Kit
The RX4i has knock-outs for connecting to conduit, or choose the power cord kit with 6ft 14awg plug cord & grommet.

Specifications

Weight 5 lbs
Product Category

Air – Water – CO2
